FIXED IND 2.2MH 240MA 8.2 OHM
| Induktivität | 2.2 mH |
| Toleranz | ±20% |
| Nennstrom | 240 mA |
| DC-Widerstand (DCR) | 8.2Ohm Max |
| saturationCurrent | - |
| Betriebstemperatur | -40°C ~ 125°C |
| Abmessungen | 0.510" L x 0.370" W (12.95mm x 9.40mm) |
| Gehäuse / Größe | Nonstandard |
| Lieferant | Abracon |
| Beschreibung | FIXED IND 2.2MH 240MA 8.2 OHM |
| Serie | ASPI-0804T |
| productStatus | Active |
| typeConstruction | Wirewound |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.217" (5.50mm) |
| features | - |
