FIXED IND 8.2UH 1.4A 135 MOHM
| Induktivität | 8.2 µH |
| Toleranz | ±30% |
| Nennstrom | 1.4 A |
| DC-Widerstand (DCR) | 135mOhm Max |
| saturationCurrent | 1.1A |
| Betriebstemperatur | -40°C ~ 125°C |
| Abmessungen | 0.189" L x 0.189" W (4.80mm x 4.80mm) |
| Gehäuse / Größe | 1919 (4848 Metric) |
| Lieferant | Bourns Inc. |
| Beschreibung | FIXED IND 8.2UH 1.4A 135 MOHM |
| Serie | SRR4018 |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 7 @ 7.96MHz |
| selfResonantFreq | 40MHz |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.079" (2.00mm) |
| features | - |
