# Inductors (Coils/Cores): A Comprehensive Guide to Series, Applications, and Design Resources

**Key Product Series and Features:**

The page details a range of inductor series, categorized by core material and key features. Each series is optimized for specific applications, including common mode filtering, normal mode filtering, PFC (Power Factor Correction), voltage boosting, and output smoothing. Here's a breakdown:

*   **Nanocrystalline Cores (FL, FL-V):**  Emphasize high permeability for common mode noise filtering and improved low-frequency performance. The FL-V series offers particularly high permeability for common mode applications, while the standard FL series is a reliable choice for common mode noise filtering.

*   **Alloy-Based Dust Cores (DM):** Optimized for downsizing and high-efficiency PFC voltage boosting coils.

*   **Amorphous Cores (KA, SM, AM, AW, CM, CMJ, BM, TM):** Offer a variety of features tailored to different needs.

    *   **KA:** Amorphous without gap, utilizing a 1-Turn structure (Low DCR) and Surface Mount Structure.
    *   **SM:** Amorphous without gap, featuring a feedthrough core with a single-turn lead wire for remarkably small D.C. resistance.
    *   **AM:** Amorphous with gap, demonstrating more excellent D.C. bias characteristics in large-current applications.
    *   **AW:** Amorphous with gap, offering downsizing compared to the AM Series for large-current applications.
    *   **CM:** Amorphous with gap, presented as a standard type in a smaller size compared to ferrite choke coils.
    *   **CMJ:** Amorphous with gap, achieving miniaturization compared to the CM Series coil by about 30%.
    *   **BM:** Amorphous without gap, offering downsizing compared to the TM Series.
    *   **TM:** Amorphous without gap, designed for downsizing and low leakage magnetic flux.

**Application Guide:**

The page clearly outlines the suitable applications for each inductor series, allowing users to quickly identify the best options for their specific design requirements. The table format provides a concise overview of which series are suitable for common mode filters, normal mode filters, PFC, voltage boosting, and output smoothing.

**Design Resources:**

To assist engineers in the design process, the page provides access to valuable resources:

*   **SPICE/S parameters:** Simulation models for accurate circuit analysis.
*   **3D-CAD:**  Downloadable 3D models for integration into CAD software.

**Additional Resources:**

Beyond product information and design tools, the page also links to important documents and information:

*   **Products FAQs:** Answers to frequently asked questions.
*   **Documents:** Technical datasheets and application notes.
*   **Catalog:** A comprehensive catalog of all available products.
*   **Confirmation report (RoHS, REACH/SVHC):** Compliance documentation.
*   **Products Guide:** A detailed product selection guide.
*   **IATF16949/ISO9001 Certification:** Quality management certifications.
*   **ISO14001 Certification:** Environmental management certification.
*   **Coil Design Request:** Enables users to request custom coil designs.
*   **Notes on Safety:** Important safety information.
*   **Quality Initiatives:** Information about the company's commitment to quality.
*   **Environmental Initiatives:** Information about the company's environmental responsibility efforts.
