FIXED IND 4.7UH 2.35A 84 MOHM
| インダクタンス | 4.7 µH |
| 許容差 | ±20% |
| 定格電流 | 2.35 A |
| 直流抵抗 (DCR) | 84mOhm Max |
| saturationCurrent | 3.7A |
| 動作温度 | -40°C ~ 125°C |
| 寸法 | 0.287" L x 0.287" W (7.30mm x 7.30mm) |
| サイズ | Nonstandard, 4 Lead |
| サプライヤー | Würth Elektronik |
| 説明 | FIXED IND 4.7UH 2.35A 84 MOHM |
| シリーズ | WE-PDA |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Nickel Zinc Ferrite (NiZn) |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | 64.7MHz |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 7345 |
| heightMax | 0.169" (4.30mm) |
| features | - |
