FIXED IND 3.9NH 300MA 140 MOHM
| インダクタンス | 3.9 nH |
| 許容差 | ±0.3nH |
| 定格電流 | 300 mA |
| 直流抵抗 (DCR) | 140mOhm Max |
| saturationCurrent | - |
| 動作温度 | -40°C ~ 85°C |
| 寸法 | 0.063" L x 0.032" W (1.60mm x 0.81mm) |
| サイズ | 0603 (1608 Metric) |
| サプライヤー | KEMET |
| 説明 | FIXED IND 3.9NH 300MA 140 MOHM |
| シリーズ | L-RMS |
| productStatus | Obsolete |
| typeConstruction | Multilayer |
| coreMaterial | Ceramic |
| shielding | Unshielded |
| qFactor | 13 @ 100MHz |
| selfResonantFreq | 8GHz |
| ratings | - |
| testFrequency | 100 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 0603 (1608 Metric) |
| heightMax | 0.028" (0.71mm) |
| features | - |
