CL0402-J473JAL4T
Knowles Voltronics
- Induktivität
- 47 nH
- Strom
- 210 mA
- DCR
- 830mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
Induktivitäts-Datenblätter
Laden Sie PDF-Datenblätter für Induktivitäten von führenden Herstellern herunter.
287 Datenblätter gefunden von Knowles Voltronics
CL0402-J272SAL4T
Knowles Voltronics
- Induktivität
- 2.7 nH
- Strom
- -
- DCR
- -
- Größe
- -
CL0402-J223JAL4T
Knowles Voltronics
- Induktivität
- 22 nH
- Strom
- 400 mA
- DCR
- 300mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0402-J562SAL4T
Knowles Voltronics
- Induktivität
- 5.6 nH
- Strom
- 760 mA
- DCR
- 83mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0402-J153JAL4T
Knowles Voltronics
- Induktivität
- 15 nH
- Strom
- 560 mA
- DCR
- 172mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0402-J472SAL4T
Knowles Voltronics
- Induktivität
- 4.7 nH
- Strom
- 640 mA
- DCR
- 130mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0402-J103JAL4T
Knowles Voltronics
- Induktivität
- 10 nH
- Strom
- 480 mA
- DCR
- 195mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0402-J682JAL4T
Knowles Voltronics
- Induktivität
- 6.8 nH
- Strom
- 680 mA
- DCR
- 83mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0402-J332SAL4T
Knowles Voltronics
- Induktivität
- 3.3 nH
- Strom
- -
- DCR
- -
- Größe
- -
CL0402-J822JAL4T
Knowles Voltronics
- Induktivität
- 8.2 nH
- Strom
- 680 mA
- DCR
- 104mOhm Max
- Größe
- 0.039 L x 0.022 W (1.00mm x 0.55mm)
CL0603-J563JAL4T
Knowles Voltronics
- Induktivität
- 56 nH
- Strom
- -
- DCR
- -
- Größe
- -
CL0603-J473JAL4T
Knowles Voltronics
- Induktivität
- 47 nH
- Strom
- 600 mA
- DCR
- 280mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J103JAL4T
Knowles Voltronics
- Induktivität
- 10 nH
- Strom
- 700 mA
- DCR
- 130mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J394JAL4T
Knowles Voltronics
- Induktivität
- 390 nH
- Strom
- -
- DCR
- -
- Größe
- -
CL0603-J123JAL4T
Knowles Voltronics
- Induktivität
- 12 nH
- Strom
- 700 mA
- DCR
- 130mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J823JAL4T
Knowles Voltronics
- Induktivität
- 82 nH
- Strom
- 400 mA
- DCR
- 540mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J224JAL4T
Knowles Voltronics
- Induktivität
- 220 nH
- Strom
- -
- DCR
- -
- Größe
- -
CL0603-J273JAL4T
Knowles Voltronics
- Induktivität
- 27 nH
- Strom
- 600 mA
- DCR
- 220mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J223JAL4T
Knowles Voltronics
- Induktivität
- 22 nH
- Strom
- 700 mA
- DCR
- 220mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J154JAL4T
Knowles Voltronics
- Induktivität
- 150 nH
- Strom
- 280 mA
- DCR
- 920mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0603-J104JAL4T
Knowles Voltronics
- Induktivität
- 100 nH
- Strom
- 400 mA
- DCR
- 630mOhm Max
- Größe
- 0.063 L x 0.041 W (1.60mm x 1.05mm)
CL0805-J824JAL4T
Knowles Voltronics
- Induktivität
- 820 nH
- Strom
- -
- DCR
- -
- Größe
- -
CL0805-J225JAL4T
Knowles Voltronics
- Induktivität
- 2.2 µH
- Strom
- -
- DCR
- -
- Größe
- -
CL0805-J154JAL4T
Knowles Voltronics
- Induktivität
- 150 nH
- Strom
- 400 mA
- DCR
- 560mOhm Max
- Größe
- 0.079 L x 0.049 W (2.00mm x 1.25mm)
CL0805-J335JAL4T
Knowles Voltronics
- Induktivität
- 3.3 µH
- Strom
- 100 mA
- DCR
- 9Ohm Max
- Größe
- 0.079 L x 0.049 W (2.00mm x 1.25mm)
| Produkt | Induktivität | Strom | DCR | Größe | Gehäuse | Aktionen |
|---|---|---|---|---|---|---|
CL0402-J473JAL4T Knowles Voltronics | 47 nH | 210 mA | 830mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J272SAL4T Knowles Voltronics | 2.7 nH | - | - | - | - | |
CL0402-J223JAL4T Knowles Voltronics | 22 nH | 400 mA | 300mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J562SAL4T Knowles Voltronics | 5.6 nH | 760 mA | 83mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J153JAL4T Knowles Voltronics | 15 nH | 560 mA | 172mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J472SAL4T Knowles Voltronics | 4.7 nH | 640 mA | 130mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J103JAL4T Knowles Voltronics | 10 nH | 480 mA | 195mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J682JAL4T Knowles Voltronics | 6.8 nH | 680 mA | 83mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0402-J332SAL4T Knowles Voltronics | 3.3 nH | - | - | - | - | |
CL0402-J822JAL4T Knowles Voltronics | 8.2 nH | 680 mA | 104mOhm Max | 0.039 L x 0.022 W (1.00mm x 0.55mm) | 0402 (1005 Metric) | |
CL0603-J563JAL4T Knowles Voltronics | 56 nH | - | - | - | - | |
CL0603-J473JAL4T Knowles Voltronics | 47 nH | 600 mA | 280mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J103JAL4T Knowles Voltronics | 10 nH | 700 mA | 130mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J394JAL4T Knowles Voltronics | 390 nH | - | - | - | - | |
CL0603-J123JAL4T Knowles Voltronics | 12 nH | 700 mA | 130mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J823JAL4T Knowles Voltronics | 82 nH | 400 mA | 540mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J224JAL4T Knowles Voltronics | 220 nH | - | - | - | - | |
CL0603-J273JAL4T Knowles Voltronics | 27 nH | 600 mA | 220mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J223JAL4T Knowles Voltronics | 22 nH | 700 mA | 220mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J154JAL4T Knowles Voltronics | 150 nH | 280 mA | 920mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0603-J104JAL4T Knowles Voltronics | 100 nH | 400 mA | 630mOhm Max | 0.063 L x 0.041 W (1.60mm x 1.05mm) | 0603 (1608 Metric) | |
CL0805-J824JAL4T Knowles Voltronics | 820 nH | - | - | - | - | |
CL0805-J225JAL4T Knowles Voltronics | 2.2 µH | - | - | - | - | |
CL0805-J154JAL4T Knowles Voltronics | 150 nH | 400 mA | 560mOhm Max | 0.079 L x 0.049 W (2.00mm x 1.25mm) | 0805 (2012 Metric) | |
CL0805-J335JAL4T Knowles Voltronics | 3.3 µH | 100 mA | 9Ohm Max | 0.079 L x 0.049 W (2.00mm x 1.25mm) | 0805 (2012 Metric) |
