BMMN00050518R47MX2
Pulse Electronics
- 인덕턴스
- 470 nH
- 전류
- 10.5 A
- DCR
- 9mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
시리즈: BMMN
시리즈 표에서 등록된 사양을 비교하세요.
BMMN
BMMN000505181R5MX1
Pulse Electronics
- 인덕턴스
- 1.5 µH
- 전류
- 5.5 A
- DCR
- 28mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505182R2MX2
Pulse Electronics
- 인덕턴스
- 2.2 µH
- 전류
- 5 A
- DCR
- 35mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505184R7MX2
Pulse Electronics
- 인덕턴스
- 4.7 µH
- 전류
- 3.5 A
- DCR
- 85mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505181R2MX2
Pulse Electronics
- 인덕턴스
- 1.2 µH
- 전류
- 7.5 A
- DCR
- 20mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505186R8MX2
Pulse Electronics
- 인덕턴스
- 6.8 µH
- 전류
- 2.8 A
- DCR
- 120mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN00050518R56MX2
Pulse Electronics
- 인덕턴스
- 560 nH
- 전류
- 9.5 A
- DCR
- 10mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505182R2MX1
Pulse Electronics
- 인덕턴스
- 2.2 µH
- 전류
- 4.7 A
- DCR
- 35mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN00050518100MX2
Pulse Electronics
- 인덕턴스
- 10 µH
- 전류
- 2.5 A
- DCR
- 155mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505183R3MX2
Pulse Electronics
- 인덕턴스
- 3.3 µH
- 전류
- 4.5 A
- DCR
- 58mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505181R0MX2
Pulse Electronics
- 인덕턴스
- 1 µH
- 전류
- 8 A
- DCR
- 17mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000505181R0MX1
Pulse Electronics
- 인덕턴스
- 1 µH
- 전류
- 7.5 A
- DCR
- 18mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN000606151R0MX2
Pulse Electronics
- 인덕턴스
- 1 µH
- 전류
- 5.5 A
- DCR
- 21mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN00060615R56MX2
Pulse Electronics
- 인덕턴스
- 560 nH
- 전류
- 9 A
- DCR
- 11mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN000606151R2MX2
Pulse Electronics
- 인덕턴스
- 1.2 µH
- 전류
- 5.4 A
- DCR
- 30mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN000606153R3MX2
Pulse Electronics
- 인덕턴스
- 3.3 µH
- 전류
- 3.3 A
- DCR
- 63mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN000606152R2MX2
Pulse Electronics
- 인덕턴스
- 2.2 µH
- 전류
- 3.5 A
- DCR
- 50mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN00060615R82MX2
Pulse Electronics
- 인덕턴스
- 820 nH
- 전류
- 7 A
- DCR
- 17mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN00060615R68MX2
Pulse Electronics
- 인덕턴스
- 680 nH
- 전류
- 8.5 A
- DCR
- 12mOhm Max
- 크기
- 0.270" L x 0.255" W (6.86mm x 6.47mm)
BMMN00060618R18MX2
Pulse Electronics
- 인덕턴스
- 180 nH
- 전류
- 17 A
- DCR
- 3.6mOhm Max
- 크기
- 0.291" L x 0.260" W (7.40mm x 6.60mm)
BMMN000404122R2MX2
Pulse Electronics
- 인덕턴스
- 2.2 µH
- 전류
- 2.75 A
- DCR
- 83.5mOhm Max
- 크기
- 0.175" L x 0.160" W (4.45mm x 4.06mm)
BMMN000404121R0MX2
Pulse Electronics
- 인덕턴스
- 1 µH
- 전류
- 4.2 A
- DCR
- 47mOhm Max
- 크기
- 0.175" L x 0.160" W (4.45mm x 4.06mm)
BMMN000404201R5MX2
Pulse Electronics
- 인덕턴스
- 1.5 µH
- 전류
- 4 A
- DCR
- 43mOhm Max
- 크기
- 0.175" L x 0.160" W (4.45mm x 4.06mm)
BMMN000505122R2MX1
Pulse Electronics
- 인덕턴스
- 2.2 µH
- 전류
- 3.5 A
- DCR
- 76mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
BMMN00050512R68MX2
Pulse Electronics
- 인덕턴스
- 680 nH
- 전류
- 6 A
- DCR
- 22mOhm Max
- 크기
- 0.216" L x 0.204" W (5.49mm x 5.18mm)
| 제품 | 인덕턴스 | 전류 | DCR | 크기 | 패키지 | 작업 |
|---|---|---|---|---|---|---|
BMMN00050518R47MX2 Pulse Electronics | 470 nH | 10.5 A | 9mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505181R5MX1 Pulse Electronics | 1.5 µH | 5.5 A | 28mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505182R2MX2 Pulse Electronics | 2.2 µH | 5 A | 35mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505184R7MX2 Pulse Electronics | 4.7 µH | 3.5 A | 85mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505181R2MX2 Pulse Electronics | 1.2 µH | 7.5 A | 20mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505186R8MX2 Pulse Electronics | 6.8 µH | 2.8 A | 120mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN00050518R56MX2 Pulse Electronics | 560 nH | 9.5 A | 10mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505182R2MX1 Pulse Electronics | 2.2 µH | 4.7 A | 35mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN00050518100MX2 Pulse Electronics | 10 µH | 2.5 A | 155mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505183R3MX2 Pulse Electronics | 3.3 µH | 4.5 A | 58mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505181R0MX2 Pulse Electronics | 1 µH | 8 A | 17mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000505181R0MX1 Pulse Electronics | 1 µH | 7.5 A | 18mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN000606151R0MX2 Pulse Electronics | 1 µH | 5.5 A | 21mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN00060615R56MX2 Pulse Electronics | 560 nH | 9 A | 11mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN000606151R2MX2 Pulse Electronics | 1.2 µH | 5.4 A | 30mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN000606153R3MX2 Pulse Electronics | 3.3 µH | 3.3 A | 63mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN000606152R2MX2 Pulse Electronics | 2.2 µH | 3.5 A | 50mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN00060615R82MX2 Pulse Electronics | 820 nH | 7 A | 17mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN00060615R68MX2 Pulse Electronics | 680 nH | 8.5 A | 12mOhm Max | 0.270" L x 0.255" W (6.86mm x 6.47mm) | Nonstandard | |
BMMN00060618R18MX2 Pulse Electronics | 180 nH | 17 A | 3.6mOhm Max | 0.291" L x 0.260" W (7.40mm x 6.60mm) | Nonstandard | |
BMMN000404122R2MX2 Pulse Electronics | 2.2 µH | 2.75 A | 83.5mOhm Max | 0.175" L x 0.160" W (4.45mm x 4.06mm) | Nonstandard | |
BMMN000404121R0MX2 Pulse Electronics | 1 µH | 4.2 A | 47mOhm Max | 0.175" L x 0.160" W (4.45mm x 4.06mm) | Nonstandard | |
BMMN000404201R5MX2 Pulse Electronics | 1.5 µH | 4 A | 43mOhm Max | 0.175" L x 0.160" W (4.45mm x 4.06mm) | Nonstandard | |
BMMN000505122R2MX1 Pulse Electronics | 2.2 µH | 3.5 A | 76mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard | |
BMMN00050512R68MX2 Pulse Electronics | 680 nH | 6 A | 22mOhm Max | 0.216" L x 0.204" W (5.49mm x 5.18mm) | Nonstandard |
