Description
FIXED IND 15NH 120MA 820 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 016008C-15NXJRW.
016008C-15NXJRW has an inductance value of 15 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
016008C-15NXJRW is rated for 120 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
016008C-15NXJRW lists a DC resistance of 820mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
016008C-15NXJRW uses a package or case of 01005 (0402 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 016008C-15NXJRW to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 15 nH |
| Tolerance | ±5% |
| Current Rating | 120 mA |
| DC Resistance (DCR) | 820mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.019" L x 0.011" W (0.47mm x 0.28mm) |
| Case / Size | 01005 (0402 Metric) |
| Package / Case | 01005 (0402 Metric) |
| Supplier | Coilcraft |
| Description | FIXED IND 15NH 120MA 820 MOHM |
| Series | 016008C |
| Packaging | Strip |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 27 @ 900MHz |
| Self Resonant Frequency | 6.2GHz |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1005 |
| Height - Seated (Max) | 0.014" (0.35mm) |
