Description
FIXED IND 5.6NH 220MA 275 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 016008C-5N6XJRW.
016008C-5N6XJRW has an inductance value of 5.6 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
016008C-5N6XJRW is rated for 220 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
016008C-5N6XJRW lists a DC resistance of 275mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
016008C-5N6XJRW uses a package or case of 01005 (0402 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 016008C-5N6XJRW to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 5.6 nH |
| Tolerance | ±5% |
| Current Rating | 220 mA |
| DC Resistance (DCR) | 275mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.019" L x 0.011" W (0.47mm x 0.28mm) |
| Case / Size | 01005 (0402 Metric) |
| Package / Case | 01005 (0402 Metric) |
| Supplier | Coilcraft |
| Description | FIXED IND 5.6NH 220MA 275 MOHM |
| Series | 016008C |
| Packaging | Strip |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 28 @ 900MHz |
| Self Resonant Frequency | 9.8GHz |
| Ratings | - |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1005 |
| Height - Seated (Max) | 0.014" (0.35mm) |
| Features | - |
