Description
FIXED IND 3.3UH 150MA 2.2 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 0402DF-332XJRW.
0402DF-332XJRW has an inductance value of 3.3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
0402DF-332XJRW is rated for 150 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
0402DF-332XJRW lists a DC resistance of 2.2Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
0402DF-332XJRW uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 0402DF-332XJRW to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.3 µH |
| Tolerance | ±5% |
| Current Rating | 150 mA |
| DC Resistance (DCR) | 2.2Ohm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.044" L x 0.026" W (1.11mm x 0.66mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Coilcraft |
| Description | FIXED IND 3.3UH 150MA 2.2 OHM |
| Series | 0402DF |
| Packaging | Strip |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | 80MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.026" (0.66mm) |
| Features | - |
