Description
FIXED IND 36NH 1.3A 55 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 0402DF-360XJRW.
0402DF-360XJRW has an inductance value of 36 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
0402DF-360XJRW is rated for 1.3 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
0402DF-360XJRW lists a DC resistance of 55mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
0402DF-360XJRW uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 0402DF-360XJRW to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 36 nH |
| Tolerance | ±5% |
| Current Rating | 1.3 A |
| DC Resistance (DCR) | 55mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.044" L x 0.026" W (1.11mm x 0.66mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Coilcraft |
| Description | FIXED IND 36NH 1.3A 55 MOHM SMD |
| Series | 0402DF |
| Packaging | Strip |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | 2.4GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.026" (0.66mm) |
| Features | - |
