Description
FIXED IND 120NH 1.4A 150 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 0603LS-121XGRC.
0603LS-121XGRC has an inductance value of 120 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
0603LS-121XGRC is rated for 1.4 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
0603LS-121XGRC lists a DC resistance of 150mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
0603LS-121XGRC uses a package or case of 0603 (1608 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 0603LS-121XGRC to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 120 nH |
| Tolerance | ±2% |
| Current Rating | 1.4 A |
| DC Resistance (DCR) | 150mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 100°C |
| Dimensions | 0.071" L x 0.044" W (1.80mm x 1.12mm) |
| Case / Size | 0603 (1608 Metric) |
| Package / Case | 0603 (1608 Metric) |
| Supplier | Coilcraft |
| Description | FIXED IND 120NH 1.4A 150 MOHM |
| Series | 0603LS |
| Packaging | Strip |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ceramic, Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 12 @ 2.5MHz |
| Self Resonant Frequency | 1.1GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0603 |
| Height - Seated (Max) | 0.044" (1.11mm) |
| Features | - |
