Description
FIXED IND 3UH 299MA 700 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 10M301J.
10M301J has an inductance value of 3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
10M301J is rated for 299 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
10M301J lists a DC resistance of 700mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
10M301J uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 10M301J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3 µH |
| Tolerance | ±5% |
| Current Rating | 299 mA |
| DC Resistance (DCR) | 700mOhm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Gowanda |
| Description | FIXED IND 3UH 299MA 700 MOHM TH |
| Series | 10M |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Iron Powder |
| Shielding | Unshielded |
| Q @ Frequency | 45 @ 7.9MHz |
| Self Resonant Frequency | 95MHz |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
