Description
FIXED IND 30UH 132MA 3.3 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 10M302J.
10M302J has an inductance value of 30 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
10M302J is rated for 132 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
10M302J lists a DC resistance of 3.3Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
10M302J uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 10M302J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 30 µH |
| Tolerance | ±5% |
| Current Rating | 132 mA |
| DC Resistance (DCR) | 3.3Ohm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Gowanda |
| Description | FIXED IND 30UH 132MA 3.3 OHM TH |
| Series | 10M |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 45 @ 2.5MHz |
| Self Resonant Frequency | 22MHz |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
