Description
FIXED IND 43UH 116MA 4.1 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 10M432J.
10M432J has an inductance value of 43 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
10M432J is rated for 116 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
10M432J lists a DC resistance of 4.1Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
10M432J uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 10M432J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 43 µH |
| Tolerance | ±5% |
| Current Rating | 116 mA |
| DC Resistance (DCR) | 4.1Ohm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Gowanda |
| Description | FIXED IND 43UH 116MA 4.1 OHM TH |
| Series | 10M |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 45 @ 2.5MHz |
| Self Resonant Frequency | 21MHz |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
