Description
FIXED IND 390UH 100MA 10 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 19M393J.
19M393J has an inductance value of 390 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
19M393J is rated for 100 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
19M393J lists a DC resistance of 10Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
19M393J uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 19M393J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 390 µH |
| Tolerance | ±5% |
| Current Rating | 100 mA |
| DC Resistance (DCR) | 10Ohm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.190" Dia x 0.440" L (4.83mm x 11.18mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Gowanda |
| Description | FIXED IND 390UH 100MA 10 OHM TH |
| Series | 19M |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Iron Powder |
| Shielding | Unshielded |
| Q @ Frequency | 65 @ 790kHz |
| Self Resonant Frequency | 4.5MHz |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
