Description
FIXED IND 560UH 91MA 12.3 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 19M563J.
19M563J has an inductance value of 560 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
19M563J is rated for 91 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
19M563J lists a DC resistance of 12.3Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
19M563J uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 19M563J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 560 µH |
| Tolerance | ±5% |
| Current Rating | 91 mA |
| DC Resistance (DCR) | 12.3Ohm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.190" Dia x 0.440" L (4.83mm x 11.18mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Gowanda |
| Description | FIXED IND 560UH 91MA 12.3 OHM TH |
| Series | 19M |
| Product Status | Active |
| Type / Construction | Molded |
| Shielding | Unshielded |
| Q @ Frequency | 65 @ 790kHz |
| Self Resonant Frequency | 3.6MHz |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
