FIXED IND 5.6UH 11.5A 6.4 MOHM
| Inductance | 5.6 µH |
| Tolerance | ±20% |
| Current Rating | 11.5 A |
| DC Resistance (DCR) | 6.4mOhm |
| saturationCurrent | 24.45A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.457" L x 0.413" W (11.60mm x 10.50mm) |
| Case / Size | Nonstandard |
| Supplier | Würth Elektronik |
| Description | FIXED IND 5.6UH 11.5A 6.4 MOHM |
| Series | WE-XHMI |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Metal Composite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | 14MHz |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.358" (9.10mm) |
| features | - |
