Description
FIXED IND 68UH 820MA 340 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 74454168.
74454168 has an inductance value of 68 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
74454168 is rated for 820 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
74454168 lists a DC resistance of 340mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
74454168 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 74454168 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 68 µH |
| Tolerance | ±15% |
| Current Rating | 820 mA |
| DC Resistance (DCR) | 340mOhm Max |
| Saturation Current | 1.35A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.500" L x 0.394" W (12.70mm x 10.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Würth Elektronik |
| Description | FIXED IND 68UH 820MA 340 MOHM |
| Series | WE-PD3 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Shielding | Shielded |
| Self Resonant Frequency | 8MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.205" (5.20mm) |
