Description
FIXED IND 36NH 500MA 180 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 744760136A.
744760136A has an inductance value of 36 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
744760136A is rated for 500 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
744760136A lists a DC resistance of 180mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
744760136A uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 744760136A to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 36 nH |
| Tolerance | ±5% |
| Current Rating | 500 mA |
| DC Resistance (DCR) | 180mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | Würth Elektronik |
| Description | FIXED IND 36NH 500MA 180 MOHM |
| Series | WE-KI |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 60 @ 500MHz |
| Self Resonant Frequency | 2GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0805 |
| Height - Seated (Max) | 0.055" (1.40mm) |
