Description
FIXED IND 1.8UH 140MA 6.26 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 7447603180A.
7447603180A has an inductance value of 1.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
7447603180A is rated for 140 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
7447603180A lists a DC resistance of 6.26Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
7447603180A uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 7447603180A to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.8 µH |
| Tolerance | ±5% |
| Current Rating | 140 mA |
| DC Resistance (DCR) | 6.26Ohm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | Würth Elektronik |
| Description | FIXED IND 1.8UH 140MA 6.26 OHM |
| Series | WE-KI |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 18 @ 50MHz |
| Self Resonant Frequency | 210MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0805 |
| Height - Seated (Max) | 0.055" (1.40mm) |
