Description
FIXED IND 82NH 400MA 540 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 744761182A.
744761182A has an inductance value of 82 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
744761182A is rated for 400 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
744761182A lists a DC resistance of 540mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
744761182A uses a package or case of 0603 (1608 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 744761182A to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 82 nH |
| Tolerance | ±5% |
| Current Rating | 400 mA |
| DC Resistance (DCR) | 540mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.063" L x 0.041" W (1.60mm x 1.05mm) |
| Case / Size | 0603 (1608 Metric) |
| Package / Case | 0603 (1608 Metric) |
| Supplier | Würth Elektronik |
| Description | FIXED IND 82NH 400MA 540 MOHM |
| Series | WE-KI |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 35 @ 150MHz |
| Self Resonant Frequency | 1.7GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 150 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0603 |
| Height - Seated (Max) | 0.049" (1.25mm) |
