FIXED IND 33UH 1.32A 165 MOHM
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating | 1.32 A |
| DC Resistance (DCR) | 165mOhm Max |
| saturationCurrent | 1.75A |
| Operating Temperature | -40°C ~ 150°C |
| Dimensions | 0.291" L x 0.287" W (7.40mm x 7.30mm) |
| Case / Size | Nonstandard |
| Supplier | Würth Elektronik |
| Description | FIXED IND 33UH 1.32A 165 MOHM |
| Series | WE-PD Performance |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | 14MHz |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.138" (3.50mm) |
| features | - |
