Description
FIXED IND 82UH 1.04A 328 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 744787820.
744787820 has an inductance value of 82 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
744787820 is rated for 1.04 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
744787820 lists a DC resistance of 328mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
744787820 uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 744787820 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 82 µH |
| Tolerance | ±20% |
| Current Rating | 1.04 A |
| DC Resistance (DCR) | 328mOhm Max |
| Saturation Current | 900mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | Würth Elektronik |
| Description | FIXED IND 82UH 1.04A 328 MOHM |
| Series | WE-PD2SR |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | 6MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.177" (4.50mm) |
| Features | - |
