Description
FIXED IND 2.7NH 150MA 800 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 744900027.
744900027 has an inductance value of 2.7 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
744900027 is rated for 150 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
744900027 lists a DC resistance of 800mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
744900027 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 744900027 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.7 nH |
| Tolerance | ±0.2nH |
| Current Rating | 150 mA |
| DC Resistance (DCR) | 800mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | Würth Elektronik |
| Description | FIXED IND 2.7NH 150MA 800 MOHM |
| Series | WE-TCI |
| Product Status | Active |
| Type / Construction | Thin Film |
| Shielding | Unshielded |
| Q @ Frequency | 8 @ 500MHz |
| Self Resonant Frequency | 8GHz |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 (0603 Metric) |
| Height - Seated (Max) | 0.011" (0.28mm) |
