Description
FIXED IND 1.2UH 7A 15.5 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 78438357012.
78438357012 has an inductance value of 1.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
78438357012 is rated for 7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
78438357012 lists a DC resistance of 15.5mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
78438357012 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 78438357012 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.2 µH |
| Tolerance | ±20% |
| Current Rating | 7 A |
| DC Resistance (DCR) | 15.5mOhm Max |
| Saturation Current | 8.8A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.161" L x 0.161" W (4.10mm x 4.10mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Würth Elektronik |
| Description | FIXED IND 1.2UH 7A 15.5 MOHM SMD |
| Series | WE-MAIA |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Iron Alloy |
| Shielding | Shielded |
| Self Resonant Frequency | 51MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 4030 |
| Height - Seated (Max) | 0.122" (3.10mm) |
