FIXED IND 27MH 16MA 308 OHM TH
| Inductance | 27 mH |
| Tolerance | ±10% |
| Current Rating | 16 mA |
| DC Resistance (DCR) | 308Ohm Max |
| saturationCurrent | 8mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) |
| Case / Size | Axial |
| Supplier | Bourns Inc. |
| Description | FIXED IND 27MH 16MA 308 OHM TH |
| Series | 9250A |
| productStatus | Obsolete |
| typeConstruction | Molded |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 27 @ 79kHz |
| selfResonantFreq | 210kHz |
| ratings | - |
| testFrequency | 79 kHz |
| mountingType | Through Hole |
| supplierDevicePackage | - |
| heightMax | - |
