Description
CAP
Specifications
Inductance
8.1 nH
Current Rating
4.4 A Max
DC Resistance (DCR)
6 mOhm Max
Parameter Guide
Understand the key electrical and mechanical specifications for AC1618SQ-8N1J.
Inductance
8.1 nH
AC1618SQ-8N1J has an inductance value of 8.1 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
4.4 A Max
AC1618SQ-8N1J is rated for 4.4 A Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
6 mOhm Max
AC1618SQ-8N1J lists a DC resistance of 6 mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from AC1618SQ-8N1J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 8.1 nH |
| Tolerance | ±5% |
| Current Rating | 4.4 A Max |
| DC Resistance (DCR) | 6 mOhm Max |
| Supplier | Bourns Inc. |
| Description | CAP |
| Product Status | Active |
| Q @ Frequency | 130 Min @ 400 MHz |
| Self Resonant Frequency | 5.2 GHz Min |
| Inductance Test Frequency | 400 MHz |
