Description
CAP
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AC2015SQ-22NG.
AC2015SQ-22NG has an inductance value of 22 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AC2015SQ-22NG is rated for 2.7 A Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AC2015SQ-22NG lists a DC resistance of 10 mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from AC2015SQ-22NG to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 22 nH |
| Tolerance | ±2% |
| Current Rating | 2.7 A Max |
| DC Resistance (DCR) | 10 mOhm Max |
| Supplier | Bourns Inc. |
| Description | CAP |
| Product Status | Active |
| Q @ Frequency | 100 Min @ 400 MHz |
| Self Resonant Frequency | 3.5 GHz Min |
| Inductance Test Frequency | 400 MHz |
