Description
FIXED IND 5.45NH 1.6A 8 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AC2213R-5N4J.
AC2213R-5N4J has an inductance value of 5.45 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AC2213R-5N4J is rated for 1.6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AC2213R-5N4J lists a DC resistance of 8mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AC2213R-5N4J uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AC2213R-5N4J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 5.45 nH |
| Tolerance | ±5% |
| Current Rating | 1.6 A |
| DC Resistance (DCR) | 8mOhm Max |
| Operating Temperature | -25°C ~ 125°C |
| Dimensions | 0.087" L x 0.056" W (2.21mm x 1.42mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 5.45NH 1.6A 8 MOHM SMD |
| Series | AC2213R |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Air |
| Shielding | Unshielded |
| Q @ Frequency | 100 @ 800MHz |
| Self Resonant Frequency | 7GHz |
| Inductance Test Frequency | 800 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.060" (1.52mm) |
