FIXED IND 4.7UH 15A 6 MOHM TH
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating | 15 A |
| DC Resistance (DCR) | 6mOhm Max |
| saturationCurrent | 16A |
| Operating Temperature | -50°C ~ 155°C |
| Dimensions | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
| Case / Size | Radial |
| Supplier | Pulse Electronics |
| Description | FIXED IND 4.7UH 15A 6 MOHM TH |
| Series | AFDI |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Metal |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Through Hole |
| supplierDevicePackage | Radial |
| heightMax | 0.394" (10.00mm) |
| features | - |
