Description
FIXED IND 4.7UH 27A 2.98 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AFDI002120104R7M01.
AFDI002120104R7M01 has an inductance value of 4.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AFDI002120104R7M01 is rated for 27 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AFDI002120104R7M01 lists a DC resistance of 2.98mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AFDI002120104R7M01 uses a package or case of Radial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AFDI002120104R7M01 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating | 27 A |
| DC Resistance (DCR) | 2.98mOhm Max |
| Saturation Current | 30A |
| Operating Temperature | -50°C ~ 155°C |
| Dimensions | 0.807" L x 0.787" W (20.50mm x 20.00mm) |
| Case / Size | Radial |
| Package / Case | Radial |
| Supplier | Pulse Electronics |
| Description | FIXED IND 4.7UH 27A 2.98 MOHM TH |
| Series | AFDI |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Metal |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 0.390" (9.90mm) |
| Features | - |
