FIXED IND 390NH 1A 90 MOHM TH
| Inductance | 390 nH |
| Tolerance | ±20% |
| Current Rating | 1 A |
| DC Resistance (DCR) | 90mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -25°C ~ 105°C |
| Dimensions | Axial |
| Case / Size | Through Hole |
| Supplier | Abracon |
| Description | FIXED IND 390NH 1A 90 MOHM TH |
| Series | AICC-02 |
| productStatus | Obsolete |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | 40 @ 25.2MHz |
| selfResonantFreq | 320MHz |
| ratings | - |
| testFrequency | 25.2 MHz |
| mountingType | - |
| supplierDevicePackage | Axial |
| heightMax | 0.110" Dia x 0.245" L (2.80mm x 6.22mm) |
| features | - |
