Description
FIXED IND 0.6NH 950MA 50 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AIMC-04UHQ-0N6W-T.
AIMC-04UHQ-0N6W-T has an inductance value of 0.6 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AIMC-04UHQ-0N6W-T is rated for 950 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AIMC-04UHQ-0N6W-T lists a DC resistance of 50mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AIMC-04UHQ-0N6W-T uses a package or case of 01005 (0402 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AIMC-04UHQ-0N6W-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 0.6 nH |
| Tolerance | ±0.05nH |
| Current Rating | 950 mA |
| DC Resistance (DCR) | 50mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.016" L x 0.008" W (0.40mm x 0.20mm) |
| Case / Size | 01005 (0402 Metric) |
| Package / Case | 01005 (0402 Metric) |
| Supplier | Abracon |
| Description | FIXED IND 0.6NH 950MA 50 MOHM |
| Series | AIMC-04UHQ |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Shielded |
| Q @ Frequency | 14 @ 500 MHz |
| Self Resonant Frequency | 17GHz |
| Ratings | - |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 01005 (0402 Metric) |
| Height - Seated (Max) | 0.013" (0.32mm) |
| Features | - |
