Description
FIXED IND 22NH 250MA 820 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AIMC-06UHQ-22NH-T.
AIMC-06UHQ-22NH-T has an inductance value of 22 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AIMC-06UHQ-22NH-T is rated for 250 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AIMC-06UHQ-22NH-T lists a DC resistance of 820mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AIMC-06UHQ-22NH-T uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AIMC-06UHQ-22NH-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 22 nH |
| Tolerance | ±3% |
| Current Rating | 250 mA |
| DC Resistance (DCR) | 820mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | Abracon |
| Description | FIXED IND 22NH 250MA 820 MOHM |
| Series | AIMC-06UHQ |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Shielded |
| Q @ Frequency | 20 @ 500 MHz |
| Self Resonant Frequency | 3GHz |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 (0603 Metric) |
| Height - Seated (Max) | 0.017" (0.42mm) |
