Description
FIXED IND 15UH 90MA 9.5 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AISC-0603F-150J-T.
AISC-0603F-150J-T has an inductance value of 15 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AISC-0603F-150J-T is rated for 90 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AISC-0603F-150J-T lists a DC resistance of 9.5Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AISC-0603F-150J-T uses a package or case of 0603 (1608 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AISC-0603F-150J-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 15 µH |
| Tolerance | ±5% |
| Current Rating | 90 mA |
| DC Resistance (DCR) | 9.5Ohm Max |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.063" L x 0.039" W (1.60mm x 1.00mm) |
| Case / Size | 0603 (1608 Metric) |
| Package / Case | 0603 (1608 Metric) |
| Supplier | Abracon |
| Description | FIXED IND 15UH 90MA 9.5 OHM SMD |
| Series | AISC-0603F |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Self Resonant Frequency | 20MHz |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0603 (1608 Metric) |
| Height - Seated (Max) | 0.047" (1.20mm) |
