FIXED IND 12UH 1.9A 49 MOHM TH
| Inductance | 12 µH |
| Tolerance | ±5% |
| Current Rating | 1.9 A |
| DC Resistance (DCR) | 49mOhm Max |
| saturationCurrent | 3.1A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.472" (12.00mm) |
| Case / Size | Radial, Vertical Cylinder |
| Supplier | Abracon |
| Description | FIXED IND 12UH 1.9A 49 MOHM TH |
| Series | AIUR-02H |
| productStatus | Obsolete |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 1 kHz |
| mountingType | Through Hole |
| supplierDevicePackage | 0.335" Dia (8.50mm) |
| heightMax | - |
| features | Radial, Vertical Cylinder |
