Description
FIXED IND 18UH 1.6A 58 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AIUR-02H-180J.
AIUR-02H-180J has an inductance value of 18 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AIUR-02H-180J is rated for 1.6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AIUR-02H-180J lists a DC resistance of 58mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AIUR-02H-180J uses a package or case of Radial, Vertical Cylinder. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AIUR-02H-180J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 18 µH |
| Tolerance | ±5% |
| Current Rating | 1.6 A |
| DC Resistance (DCR) | 58mOhm Max |
| Saturation Current | 2.66A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.472" (12.00mm) |
| Case / Size | Radial, Vertical Cylinder |
| Package / Case | Radial, Vertical Cylinder |
| Supplier | Abracon |
| Description | FIXED IND 18UH 1.6A 58 MOHM TH |
| Series | AIUR-02H |
| Product Status | Obsolete |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | 0.335" Dia (8.50mm) |
| Features | Radial, Vertical Cylinder |
