Description
FIXED IND 100NH 24A 2 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AMDLH4020S-R10MT.
AMDLH4020S-R10MT has an inductance value of 100 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AMDLH4020S-R10MT is rated for 24 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AMDLH4020S-R10MT lists a DC resistance of 2mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AMDLH4020S-R10MT uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AMDLH4020S-R10MT to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 100 nH |
| Tolerance | ±20% |
| Current Rating | 24 A |
| DC Resistance (DCR) | 2mOhm Max |
| Saturation Current | 26A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.165" L x 0.161" W (4.20mm x 4.10mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Abracon |
| Description | FIXED IND 100NH 24A 2 MOHM SMD |
| Series | AMDLH4020S |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Alloy |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.083" (2.10mm) |
| Features | Low DCR, Soft Saturation |
