FIXED IND 2.2UH 2.85A 90 MOHM
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating | 2.85 A |
| DC Resistance (DCR) | 90mOhm Max |
| saturationCurrent | 6A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.175" L x 0.160" W (4.45mm x 4.06mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2.2UH 2.85A 90 MOHM |
| Series | AMMA |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Metal |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.079" (2.00mm) |
| features | - |
