Description
FIXED IND 1.5UH 10A 14 MOHM SMD
Specifications
Inductance
1.5 µH
Current Rating
10 A
DC Resistance (DCR)
14mOhm Max
Dimensions
0.287" L x 0.268" W (7.30mm x 6.80mm)
Product Attributes
Manufacturer Verified
Last verified: 6/18/2026| Inductance | 1.5 µH |
| Tolerance | ±20% |
| Current Rating | 10 A |
| DC Resistance (DCR) | 14mOhm Max |
| saturationCurrent | 14A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.287" L x 0.268" W (7.30mm x 6.80mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1.5UH 10A 14 MOHM SMD |
| Series | AMQx |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Metal |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.118" (3.00mm) |
| features | - |
