Description
FIXED IND 470UH 460MA 1.44 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for APCA00070745471M00.
APCA00070745471M00 has an inductance value of 470 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
APCA00070745471M00 is rated for 460 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
APCA00070745471M00 lists a DC resistance of 1.44Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
APCA00070745471M00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from APCA00070745471M00 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 470 µH |
| Tolerance | ±20% |
| Current Rating | 460 mA |
| DC Resistance (DCR) | 1.44Ohm Max |
| Saturation Current | 370mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.291" L x 0.276" W (7.40mm x 7.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 470UH 460MA 1.44 OHM |
| Series | APCA |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.189" (4.80mm) |
