FIXED IND 2.2UH 4.4A 24.09 MOHM
| Inductance | 2.2 µH |
| Tolerance | ±30% |
| Current Rating | 4.4 A |
| DC Resistance (DCR) | 24.09mOhm Max |
| saturationCurrent | 1.86A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.343" L x 0.291" W (8.70mm x 7.40mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2.2UH 4.4A 24.09 MOHM |
| Series | APSR |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.098" (2.50mm) |
| features | - |
