Description
FIXED IND 8.9NH 2.9A 7 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AS0608N9JTR.
AS0608N9JTR has an inductance value of 8.9 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AS0608N9JTR is rated for 2.9 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AS0608N9JTR lists a DC resistance of 7mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AS0608N9JTR uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AS0608N9JTR to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 8.9 nH |
| Tolerance | ±5% |
| Current Rating | 2.9 A |
| DC Resistance (DCR) | 7mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.064 L x 0.072 W (1.63mm x 1.83mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | KYOCERA AVX |
| Description | FIXED IND 8.9NH 2.9A 7 MOHM SMD |
| Series | AS |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Air |
| Shielding | Unshielded |
| Q @ Frequency | 90 @ 400MHz |
| Self Resonant Frequency | 4.3GHz |
| Inductance Test Frequency | 400 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0608 (1618 Metric) |
| Height - Seated (Max) | 0.059 (1.51mm) |
