Description
FIXED IND 220UH 750MA 819 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for ASPI-0840-221M-T.
ASPI-0840-221M-T has an inductance value of 220 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
ASPI-0840-221M-T is rated for 750 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
ASPI-0840-221M-T lists a DC resistance of 819mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
ASPI-0840-221M-T uses a package or case of Surface Mount. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from ASPI-0840-221M-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 220 µH |
| Tolerance | ±20% |
| Current Rating | 750 mA |
| DC Resistance (DCR) | 819mOhm Max |
| Saturation Current | 750mA |
| Operating Temperature | -40°C ~ 85°C |
| Case / Size | Surface Mount |
| Package / Case | Surface Mount |
| Supplier | Abracon |
| Description | FIXED IND 220UH 750MA 819 MOHM |
| Series | ASPI-0840 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Supplier Device Package | Nonstandard |
| Height - Seated (Max) | 0.315" L x 0.315" W (8.00mm x 8.00mm) |
| Features | 0.169" (4.30mm) |
