Description
FIXED IND 6.8UH 710MA 443 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for ASPI-2510-6R8M-T2.
ASPI-2510-6R8M-T2 has an inductance value of 6.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
ASPI-2510-6R8M-T2 is rated for 710 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
ASPI-2510-6R8M-T2 lists a DC resistance of 443mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
ASPI-2510-6R8M-T2 uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from ASPI-2510-6R8M-T2 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 6.8 µH |
| Tolerance | ±20% |
| Current Rating | 710 mA |
| DC Resistance (DCR) | 443mOhm |
| Saturation Current | 680mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | Abracon |
| Description | FIXED IND 6.8UH 710MA 443 MOHM |
| Series | ASPI-2510 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 2510 |
| Height - Seated (Max) | 0.039" (1.00mm) |
