Description
FIXED IND 1UH 13.7A 8.35 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for ASPI-8030HS-1R0N-T.
ASPI-8030HS-1R0N-T has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
ASPI-8030HS-1R0N-T is rated for 13.7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
ASPI-8030HS-1R0N-T lists a DC resistance of 8.35mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
ASPI-8030HS-1R0N-T uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from ASPI-8030HS-1R0N-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 µH |
| Tolerance | ±30% |
| Current Rating | 13.7 A |
| DC Resistance (DCR) | 8.35mOhm Max |
| Saturation Current | 29A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.339" L x 0.323" W (8.60mm x 8.20mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Abracon |
| Description | FIXED IND 1UH 13.7A 8.35 MOHM |
| Series | ASPI-8030HS |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Metal Composite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.118" (3.00mm) |
