Description
FIXED IND 1UH SURFACE MOUNT
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for ASPI-M3015-1R0M-T.
ASPI-M3015-1R0M-T has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
ASPI-M3015-1R0M-T is rated for 3.6 A Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
ASPI-M3015-1R0M-T lists a DC resistance of 48 mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
ASPI-M3015-1R0M-T uses a package or case of Nonstandard, 2 Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from ASPI-M3015-1R0M-T to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 µH |
| Tolerance | ±20% |
| Current Rating | 3.6 A Max |
| DC Resistance (DCR) | 48 mOhm Max |
| Saturation Current | 5.3 A Max |
| Dimensions | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
| Case / Size | Nonstandard, 2 Lead |
| Package / Case | Nonstandard, 2 Lead |
| Supplier | Abracon |
| Description | FIXED IND 1UH SURFACE MOUNT |
| Series | ASPI-M |
| Product Status | Active |
| Shielding | Unshielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.059" (1.50mm) |
