Description
FIXED IND 180NH 50A 0.25 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for ATL-1Z120705SR18MT.
ATL-1Z120705SR18MT has an inductance value of 180 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
ATL-1Z120705SR18MT is rated for 50 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
ATL-1Z120705SR18MT lists a DC resistance of 0.25mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
ATL-1Z120705SR18MT uses a package or case of Surface Mount. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from ATL-1Z120705SR18MT to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 180 nH |
| Tolerance | ±20% |
| Current Rating | 50 A |
| DC Resistance (DCR) | 0.25mOhm |
| Saturation Current | 38A |
| Operating Temperature | -40°C ~ 125°C |
| Case / Size | Surface Mount |
| Package / Case | Surface Mount |
| Supplier | Abracon |
| Description | FIXED IND 180NH 50A 0.25 MOHM |
| Series | ATL-1Z120705S |
| Product Status | Active |
| Type / Construction | Molded |
| Shielding | Unshielded |
| Inductance Test Frequency | 100 kHz |
| Supplier Device Package | Nonstandard, 4 Lead |
| Height - Seated (Max) | 0.472" L x 0.276" W (12.00mm x 7.00mm) |
| Features | 0.197" (5.00mm) |
