FIXED IND 4.7UH 950MA 285 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for AWVF002520104R7M00.
AWVF002520104R7M00 has an inductance value of 4.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
AWVF002520104R7M00 is rated for 950 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
AWVF002520104R7M00 lists a DC resistance of 285mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
AWVF002520104R7M00 uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from AWVF002520104R7M00 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating | 950 mA |
| DC Resistance (DCR) | 285mOhm |
| Saturation Current | 920mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 4.7UH 950MA 285 MOHM |
| Series | AWVF |
| Product Status | Active |
| Core Material | Ferrite |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 1 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.040" (1.02mm) |
